Technical Datasheet

DS-IND-MULTI-CORE-COPPER-FLEXIBLE-CABLES-01 | Page 01

Flexible Cables

Multi-core Copper Flexible Cables

Extremely flexible multi-core cable woven from fine gauge bare copper wires. Ideal for dynamic automation setups, portable tools, and power supply lines that undergo continuous bending.

Product Build Up (Construction)

Visual Render

External Sheathing

CAD Cross-Section

Internal Core Layout

Conductor Detail

Metallurgy Gauge

Key Features

•Class 5/6 flexible conductor stranding for dynamic bending
•Excellent resistance to oils, chemicals, and industrial acids
•High shielding coverage for superior noise suppression
•Tested for continuity and high-voltage insulation stability

Applications

CNC machine automation panelsAppliance motor wiringSwitchboard control instrumentationIndustrial sensor networks

LɅNKɅBLECONNECTING POSSIBILITIES

Technical Datasheet

DS-IND-MULTI-CORE-COPPER-FLEXIBLE-CABLES-01 | Page 02

Detailed Engineering Specifications

Materials & Build

Conductor Metallurgy: Class 2 Stranded Bare Copper / Aluminum
Insulation Compound: PVC / XLPE Insulation
Outer Sheath: FR-PVC (Flame Retardant PVC)
Armouring: Unarmoured

Electrical Parameters

Voltage Rating: 1100 V (1.1 kV)
Test Voltage: 3000 V AC
Operating Temperature: Max. 70°C (PVC) / 90°C (XLPE)

Mechanical & Thermal

Bending Radius (Fixed): 12 x Outer Diameter (Armoured)
Flame Retardancy: IEC 60332-1-2
Short Circuit Temp: 160°C (for PVC) / 250°C (for XLPE)

Compliance & Quality

Standards: IS 1554 (Part-1), IEC 60502-1
Quality Certs: CE, RoHS Compliant, ISO 9001

CE compliantRoHS certifiedISO 9001

Quality Assurance Seal

100% In-house Tested & Certified

Sales & Sales Head Office

Sitapura Industrial Area, Jaipur, Rajasthan 302022, India

Email: sales@lankable.com

Phone: +91 99500 52179

Web: www.lankable.com

Disclaimer: Specifications are subject to change without notice. All dimensions, weights, and electrical properties are nominal values.
