Technical Datasheet

DS-IND-AVSS-01 | Page 01

Automotive Cable Single Core

AVSS Cable

PVC-insulated single-core automotive cable for low-voltage circuits in automobiles, vehicles, and motorcycles, with bare Cu-ETP copper conductor per JIS 3120 and PVC insulation compliant with JASO D 611-94.

Product Build Up (Construction)

Visual Render

External Sheathing

CAD Cross-Section

Internal Core Layout

Conductor Detail

Metallurgy Gauge

Key Features

•Bare Cu-ETP copper conductor per JIS 3120
•Thin-wall PVC insulation per JASO D 611-94
•Rated for low-voltage circuits in cars and motorcycles
•Supports flexible stranded and flexible finer-strand conductor formats

Applications

Low-voltage circuit wiring in automobiles and vehiclesMotorcycle electrical harnessesGeneral automotive body wiringApplications requiring JASO D611 compliance

LɅNKɅBLECONNECTING POSSIBILITIES

Technical Datasheet

DS-IND-AVSS-01 | Page 02

Detailed Engineering Specifications

Materials & Build

Conductor Metallurgy: Class 2 Stranded Bare Copper / Aluminum
Insulation Compound: PVC / XLPE Insulation
Outer Sheath: FR-PVC (Flame Retardant PVC)
Armouring: Unarmoured

Electrical Parameters

Voltage Rating: 1100 V (1.1 kV)
Test Voltage: 3000 V AC
Operating Temperature: Max. 70°C (PVC) / 90°C (XLPE)

Mechanical & Thermal

Bending Radius (Fixed): 12 x Outer Diameter (Armoured)
Flame Retardancy: IEC 60332-1-2
Short Circuit Temp: 160°C (for PVC) / 250°C (for XLPE)

Compliance & Quality

Standards: IS 1554 (Part-1), IEC 60502-1
Quality Certs: CE, RoHS Compliant, ISO 9001

CE compliantRoHS certifiedISO 9001

Quality Assurance Seal

100% In-house Tested & Certified

Sales & Sales Head Office

Sitapura Industrial Area, Jaipur, Rajasthan 302022, India

Email: sales@lankable.com

Phone: +91 99500 52179

Web: www.lankable.com

Disclaimer: Specifications are subject to change without notice. All dimensions, weights, and electrical properties are nominal values.
